ITEM |
DESCRIPTION |
|
Continuous Voltage |
DC 48V |
|
DC Brushless Motor |
5HP |
|
Cooling System |
Air-Cooling |
|
Derailleur |
Electric auto-derailleur |
|
Over-load protection |
80Ah ±
5% |
|
Max. carrying capacity |
FRONT : 30KG / REAR : 40KG |
|
Climbing capability |
≦35ﾟ |
|
Max. speed(1st speed) |
36 km/hr (rpm 2300)
≤500kg |
|
Max. speed(2nd speed) |
45 km/hr (rpm 2800)
≤500kg |
|
Cruising range(1st speed) |
RANGE : 72KM (36 km/hr for 120
mins) |
|
Cruising range(2nd speed) |
RANGE : 68KM (45 km/hr for 90
mins) |
|
Brake Front |
Drum |
|
Brake Rear |
Disc |
|
Front Tire |
23x7 -10 |
|
Rear Tire |
22x12-10 |
|
Overall Dimension |
1650 x 960 x 1050mm |
|
Wheelbase |
1060mm |
|
Dry Weight(without battery) |
185KG |
|
Battery |
LiFePO4 (DC 48V/20AH) /
3PCS=24KG |
